Kensington SmartFit Mounting Arm for Monitor, Flat Panel Display, Curved Screen Display - Landscape/Portrait, Height Adjustable, 1 Display(s) Supported, 13" to 32" Screen Support, 75 x 75, 100 x 100
Click image to zoom in
-
Free Shipping
-
Secure Shopping
-
NET-30 Terms
-
Made In USA
Product Details
Product Highlights
- SmartFit system to find the proper monitor height for maximum comfort
- Height adjusts from 6-7/10" to 19-9/10"; swivels, rotates and tilts 90 degrees
- Counterbalance tension adjustment to tighten or loosen arm, accommodating a range of monitor weights
- Fully articulating design for total control of your monitor placement; supports 13" to 34" flat or curved monitor up to 19.8 lb.
- Mount using C-clamp on desks up to 3-3/10" or mount using a grommet hole
Product Documents
SmartFit One-Touch Height-Adjustable Single Monitor Arm makes it easy to find the proper monitor height and a neutral, comfortable posture with its patented SmartFit System and fully articulating design. It is tested to meet ANSI/BIFMA standards. Heavy-duty construction guarantees stability in every position. Gas-spring monitor mount allows you to effortlessly adjust your monitor's height, depth and angle (landscape to portrait). Height adjusts from 6-7/10" to 19-9/10". Counterbalance tension adjustment allows you to tighten or loosen the arm to accommodate a range of monitor weights with the same effortlessness and stability. It supports a 13" to 34" flat or curved monitor weighing up to 19.8 lb. Monitor arm lifts your external monitor up and out of the way to declutter and clear valuable desk space. Cable-management system organizes and conceals cables. Use the C-clamp to mount on desktops up to 3-3/10" thick or mount using a grommet hole.
Product Specifications
| Dimensions / Specifications | |
|---|---|
| Unit of Measure | EA |
| Item Dimensions | 12.60 in. x 4.60 in. x 19.20 in. (W x H x D) |
| Item Weight | 9.050 lbs |
| Carton Pack Quantity | 4 EA |
| This item is sold by the EA | |
| Shipping Info | |
|---|---|
| Can Ship via UPS? | Yes |
| Can Ship via Air Carrier? | Yes |
| Hazmat restrictions? | No |
| Additional Information | |
|---|---|
| Considered Green (less environmental impact)? | No |
| Made of Some or All Recycled Materials? | No |
| Item Specifications | |
|---|---|
| Manufacturer | Kensington Computer Products Group |
| Manufacturer Part Number | 55470 |
| Product Line | SmartFit |
| Product Name | SmartFit One-Touch Height Adjustable Single Monitor Arm |
| Packaged Quantity | 1 Each |
| Product Type | Mounting Arm |
| Device Supported | Monitor |
| Device Supported | Flat Panel Display |
| Device Supported | Curved Screen Display |
| Number of Displays Supported | 1 |
| Minimum Load Capacity | 19.84 lb |
| Minimum Screen Size Supported | 13" |
| Maximum Screen Size Supported | 32" |
| Features | Adjustable Depth |
| Features | Adjustable Angle |
| Features | Ergonomic Design |
| Features | 180° Swivel |
| Features | +/- 90° Tilt |
| Features | Articulating |
| Features | Easy to Apply |
| Features | Grommet |
| Orientation | Landscape/Portrait |
| Minimum Extended Height | 6.70" |
| Height Adjustable | Yes |
| VESA Mount Compatible | Yes |
| Mounting Pattern | 75 x 75 |
| Mounting Pattern | 100 x 100 |
| Form Factor | Desk |
| Height | 19.90" |
| Weight (Approximate) | 9.30 lb |
| Package Contents | SmartFit One-Touch Height Adjustable Single Monitor Arm, Tool Kit |
| Application/Usage | Office |
| Compatibility | Kensing - SmartFit Sit/Stand Desk (K52804WW) |
| Country of Origin | China |
| Limited Warranty | 24 Month |
| Manufacturer Info | |
|---|---|
| Brand | Kensington® (website) |
| Brand Contact | 800-535-4242 |
| Manufacturer SKU | 55470 |
| Retail GTIN (UPC) | |
| Country of Origin | CN |
| UNSPSC Number | |
| Product ID | 10000024 |
